Polytetrafluoroethylene (PTFE), commonly known by the brand name Teflon, is a synthetic fluoropolymer of tetrafluoroethylene renowned for its remarkable non-stick, low friction, and chemical resistance properties. Developed in the late 1930s by DuPont, PTFE has since become a versatile material used in various industries and applications. While PTFE is highly advantageous, there are considerations regarding its environmental impact and potential health concerns when overheated beyond its stable temperature range, which can release harmful fumes. Overall, PTFE (Teflon) is a highly valuable material in modern technology and everyday life due to its unique combination of non-stick, chemical resistance, and thermal properties.
Pipe: ASTM A 106 Grade B schedule 80 br
Flange: IS 2062 Grade B. ANSI B 16.5 ASA 150 # for drilled holesbr
Standard: Two axed flanges, loose flange available on requestbr
Lining: Pure PTFE in compliance with ASTM D 1457, white in colorbr
Lining thickness: 3 to 5 mm, exceeds the relevant ASTM F-1545 standard specsbr
Operating temperature: PTFE -29 to 260 deg. Cbr
Operating pressure: Vacuum to 6 kg/cm. sq.br
Hydrostatic pressure test: 10 kg/cm. sqbr
Air leak test: 3 kg/cm. sq.br
Spark test: 10 KV
Manufactured in carbon steel and lined inside and outside with PTFE extruded liner, they are designed to bring the product work efficiently in corrosive environment.
We provide custom service for the PTFE/PP coating for the pipes and fittings
We provide custom product as per your specification.
